Fixed Equipment On-Stream Inspection Training

  • Online (Microsoft Teams)
  • +971 562069465
  • info@velosiaims.com
Course Overview

  • This course focuses on the principles and application of on-stream inspection for fixed equipment operating under pressure and temperature, in accordance with API 510, API 570, and API 653 requirements. It is thoroughly structured and explains when on-stream inspection is permitted, its limitations, and the inspector’s responsibilities while equipment remains in service. Participants learn to identify active damage mechanisms such as corrosion, erosion, CUI, and cracking using API RP 575 guidance.

    The course covers common inspection tools and techniques, including visual inspection, ultrasonic thickness measurement, and leak detection, as well as their limitations in operation. Emphasis is placed on recognizing early warning signs that may require increased monitoring, escalation, or shutdown. Practical case examples demonstrate how inspection findings are evaluated, documented, and translated into integrity and risk-based decisions. It equips inspectors and engineers with the skills needed to assess equipment condition and support sound operational integrity decisions safely.

Learning Objectives

  • By the end of this course, participants should be able to:

    • Understand the purpose and limits of on-stream inspection
    • Apply API 510, 570, and 653 requirements during operation
    • Identify active damage mechanisms using API RP 575
    • Select proper on-stream inspection techniques
    • Recognize warning signs requiring shutdown or escalation
    • Document findings and make sound integrity recommendations
Mode of Delivery

  • Training will be conducted via Microsoft Team Meeting. Meeting invites will be shared one day before the first day of training.

    Face-to-face training is available as per request.

Training Timings

  • 02 days of training from 09:00 AM to 03:00 PM GST (UAE Time)

Training Timings

  • 03 days of training from 09:00 AM to 03:00 PM GST (UAE Time)

Materials Provided
    • Presentation Slides
    • Study References
Certificate

  • Upon successful completion of training, participants will receive a ""Fixed Equipment On-Stream Inspection" training course completion certificate.

Who Should Attend

  • This course is appropriate for a wide range of professionals, but not limited to:

    • Inspectors (API 510 / 570 / 653)
    • Integrity and mechanical engineers
    • QA/QC and reliability personnel
    • Operations engineers involved in inspection support
    • Maintenance planners and supervisors
How can we help you?

Contact us at the Velosi office nearest to you or submit a business inquiry online.

contact us

Fees + VAT as applicablee

Tax Registration Number: 100442245500003

(including coffee breaks and a buffet lunch daily)

Discount Plans

Course Outline

Day 01

  • Fundamentals & On-Stream Inspection Techniques

    Day 1 – Session 1

    Introduction to On-Stream Inspection

    • Definition and importance of on-stream inspection

    • When on-stream inspection is allowed vs not allowed

    • Code hierarchy and overlap:

    • API 510 (vessels)

    • API 570 (piping)

    • API 653 (tanks)

    • Inspector responsibilities and limitations

    Day 1 – Session 2

    On-Stream Inspection Requirements by Code

    • API 510 on-stream inspection scope

    • API 570 on-stream inspection intervals and locations

    • API 653 external and in-service inspection requirements

    • Differences between external, internal, and on-stream inspections

    • Documentation and inspection records

    Day 1 – Session 3

    Inspection Tools and Techniques (While in Service)

    • Visual inspection (VT) essentials

    • Ultrasonic thickness measurement (UT)

    • Temperature measurement and thermography (overview)

    • Leak detection methods

    • Limitations of NDT during operation

    (API RP 572 & RP 574 guidance applied)

    Day 1 – Session 4

    Typical On-Stream Inspection Locations

    • Pressure vessels:

    • Shell, heads, nozzles, supports

    • Piping systems:

    • Elbows, reducers, dead legs, low points

    • Storage tanks:

    • Shell courses, roof, nozzles, and foundation edge

    • Identifying corrosion-prone areas



Day 02

  • Damage Mechanisms, Evaluation & Decision-Making

    Day 2 – Session 1

    Active Damage Mechanisms (API RP 575)

    • General and localized corrosion

    • CUI indicators during operation

    • Erosion and erosion-corrosion

    • SCC awareness (chloride, caustic, sulfide)

    • Thermal fatigue and vibration damage

    Day 2 – Session 2

    Leak Indicators & Early Warning Signs

    • Staining, wet spots, rust blooms

    • Insulation damage and hot spots

    • Product odor and vapor indicators

    • Abnormal temperature or vibration

    • When a finding becomes critical

    Day 2 – Session 3

    Evaluation, Monitoring & Integrity Decisions

    • Thickness trending and corrosion rate basics

    • Remaining life concept (awareness level)

    • API acceptance philosophy (high level)

    • When to:

    • Continue monitoring

    • Increase inspection frequency

    • Recommend a shutdown or repair

    • Interface with API 579 (FFS awareness only)

    Day 2 – Session 4

    Reporting, Case Examples & Lessons Learned

    • On-stream inspection report essentials

    • Clear documentation of limitations

    • Communication with operations and management

    Mini Case Examples:

    • UT thinning detected on live piping elbow

    • External corrosion on the operating pressure vessel

    • Tank shell corrosion found during in-service inspection

    • Wrap-up & Q&A
